Net Power
Power Range: 600 - 2000 VA
Ideal for PC protection.
The Net Power series includes the 600-2000 VA models and uses digital Line Interactive (VI) technology.
The load is powered from the mains through an AVR to stabilise brownout, sag and surge voltages, and EMI filters to suppress spikes and transients. When the mains fails, the load is powered by the inverter with a pseudo sinewave to provide sufficient runtime for computer system shutdown using the PowerShield³.
5 models in this range · quoted to order by an authorized Riello UPS reseller
Highlights
- Automatic Voltage Regulation (AVR)
- Advanced communications
- Automatic battery test
Models & ordering
Riello model designations are the order codes. Each model is quoted to order; open a model for its full specification and to request pricing and lead time.
| Model | Rated power | Active power | Dimensions (h w d) | Weight | |
|---|---|---|---|---|---|
| NPW 600 | 600 VA | 360 W | 142x100x287 mm | 4.3 kg | Quote |
| NPW 800 | 800 VA | 480 W | 142x100x287 mm | 4.9 kg | Quote |
| NPW 1000 | 1000 VA | 600 W | 350x160x146 mm | 8 kg | Quote |
| NPW 1500 | 1500 VA | 900 W | 397x205x146 mm | 11.1 kg | Quote |
| NPW 2000 | 2000 VA | 1200 W | 397x205x146 mm | 11.5 kg | Quote |
Ships from and sold by A5 IT.
| Input | |
| Rated power | 600 VA |
|---|---|
| Voltage | 220 / 230 / 240 V |
| Voltage tolerance | 230 V (±25%) |
| Frequency | 50 / 60 Hz with automatic selection |
| OUTPUT and INVERTER OUTPUT | |
| Rated power | 600 VA |
| Active power | 360 W |
| Wave form on battery | Pseudo sinusoidal |
| Frequency on battery operation | 50 or 60 Hz (±0.5%) |
| Batteries | |
| Type | VRLA AGM maintenance-free lead based |
| Typical recharge time | 6-8 h |
| Environmental | |
| Color | Black |
| Communication | USB |
| Accessories provided | 2 cables for powering loads; user manual |
| Marks | CE |
| Operating temperature | 0 °C - +40 °C |
| Relative humidity | 5-95% non-condensing |
| Standards | European directives: L V 2014/35/EU low voltage; EMC 2014/30/EU electromagnetic compatibility -- Directive and Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; RoHS compliant |
| Data | |
| Weight | 4.3 kg |
| Dimensions (h w d) | 142x100x287 mm |
Characteristics
Advanced communications
- Mains power supply stabilisation and filtering (Line Interactive (VI) technology with AVR and filters for atmospheric disturbance suppression).
- Cold Start capability: the UPS can power up without a mains supply present.
- High reliability with built-in battery test feature.
- Supplied with 2 output cables.
- USB port.
2-year warranty
