iDialog Rack
Power Range: 600 - 1200 VA
Maximum reliability in the protection of Voip systems.
Maximum reliability in the protection of Voip systems. The iDialog Rack range is the ideal solution for protecting PCs and peripherals in the home and office.
IT equipment such as PCs, Media Centres and peripherals, TVs, Home Cinema systems, Satellite and Digital Terrestrial,Receivers and DVD recorders and players;
xDSL modems and routers;
Voip and network application.
2 models in this range · quoted to order by an authorized Riello UPS reseller
Highlights
- Design for telco rack
- Silent operation
- Auto restart
- Low power consumption
Models & ordering
Riello model designations are the order codes. Each model is quoted to order; open a model for its full specification and to request pricing and lead time.
| Model | Rated power | Active power | Dimensions (h w d) | Weight | |
|---|---|---|---|---|---|
| IDR 600 | 600 VA | 360 W | 87x438x230 mm | 5.5 kg | Quote |
| IDR 1200 | 1200 VA | 720 W | 87x438x300 mm | 9 kg | Quote |
Ships from and sold by A5 IT.
| Input | |
| Rated power | 600 VA |
|---|---|
| Voltage | 220 / 230 / 240 V |
| Voltage tolerance | 230 V (+20/-25%) |
| Frequency | 50 / 60 Hz with automatic selection |
| OUTPUT and INVERTER OUTPUT | |
| Rated power | 600 VA |
| Active power | 360 W |
| Number phases | 1 |
| Wave form on battery | Pseudo Sinusoidal |
| Frequency on battery operation | 50 or 60 Hz (±1%) |
| Batteries | |
| Type | VRLA AGM maintenance-free lead based |
| Typical recharge time | 6-8 h |
| Environmental | |
| Communication | USB + RS232 |
| Accessories provided | Rack handles, user manual |
| Protection rating | 1 |
| Marks | CE |
| Operating temperature | 0 °C - +40 °C |
| Relative humidity | 5-95% non-condensing |
| Standards | European directives: L V 2014/35/EU low voltage; EMC 2014/30/EU electromagnetic compatibility -- Directive and Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; RoHS compliant |
| Data | |
| Weight | 5.5 kg |
| Dimensions (h w d) | 87x438x230 mm |
Characteristics
Silent operation
The UPS is silent in operation (0 dBA) thanks to its use of a fan-free design and high frequency components.
Advanced communications
PowerShield 3 software allows for the safe shutdown of connected IT systems on mains power supply failure. PowerShield 3 provides efficient and intuitive UPS management using bar chart displays for important operating information.
Auto restart
The UPS automatically restarts when the mains power supply is restored.
ECO Line environmental protection
With energy savings in mind, the iDialog Rack range features a shut-off button to reduce energy consumption during periods of prolonged inactivity.
