iPlug
Power Range: 600 - 800 VA
Versatile, robust and contemporary design.
The iPlug series is the ideal solution for household, and small home office systems. Its compact size and versatility - push-button operation, LED status panel and user-replaceable batteries - make iPlug easy to install within a domestic environment to protect systems from surges and blackouts. When mains power fails the load is powered by the inverter and built-in battery. PowerShield³ UPS monitoring and control software can be used for an orderly unattended shutdown of IT systems.
2 models in this range · quoted to order by an authorized Riello UPS reseller
Highlights
- Compact
- Versatile
- Robust
- Contemporary design
- Auto restart
- Battery swap
Models & ordering
Riello model designations are the order codes. Each model is quoted to order; open a model for its full specification and to request pricing and lead time.
| Model | Rated power | Active power | Dimensions (h w d) | Weight | |
|---|---|---|---|---|---|
| IPG 800 | 800 VA | 480 W | 99x185x313 mm | 4.1 kg | Quote |
| IPG 600 | 600 VA | 360 W | 99x185x313 mm | 3.7 kg | Quote |
Ships from and sold by A5 IT.
| Input | |
| Rated power | 800 VA |
|---|---|
| Voltage | 220 / 230 / 240 V |
| Voltage tolerance | 230 V (+20/-25%) |
| Frequency | 50 / 60 Hz with automatic selection |
| OUTPUT and INVERTER OUTPUT | |
| Rated power | 800 VA |
| Active power | 480 W |
| Number phases | 1 |
| Wave form on battery | Pseudo Sinusoidal |
| Frequency on battery operation | 50 or 60 Hz (+/- 1%) |
| Batteries | |
| Type | VRLA AGM maintenance-free lead based |
| Typical recharge time | 6-8 h |
| Environmental | |
| Color | Black |
| Communication | USB |
| Accessories provided | power cable, user guide |
| Marks | CE; GS/NEMKO on Schuko version |
| Operating temperature | 0 °C - +40 °C |
| Relative humidity | 5-95% non-condensing |
| Output sockets | 6 sockets (Schuko or Italian or French or British) + 2 IEC 320 C13 |
| Standards | European directives: L V 2014/35/EU low voltage; EMC 2014/30/EU electromagnetic compatibility -- Directive and Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; RoHS compliant |
| Data | |
| Weight | 4.1 kg |
| Dimensions (h w d) | 99x185x313 mm |
Characteristics
Features
- ECO LINE energy efficient product
- Compact, ergonomic design
- 5 sockets with battery backup
- 3 sockets with surge protection only
- Cold start capability to power up the UPS without mains power
- User replaceable batteries
- USB interface for remote monitoring
- Power cable included
- Protection from short-circuits
- Auto restart - when the mains returns after battery exhaustion
- GS/Nemko safety marking
- Available with French (2P+T), English, Schuko and Italian outlets.
Advanced communication
- PowerShield 3 supervision and shutdown software for Windows operating systems 10, 8, 7, Hyper-V, 2019, 2016, 2012, and previous versions, Mac OS X, Linux
- Plug and Play function.
