iDialog
Power Range: 400 - 1600 VA
Maximum reliability in the protection of PCs.
The iDialog range is the ideal solution for the protection of PCs and peripherals in the home and in office environments. iDialog is an easy-to-install, economic solution for anyone wishing to protect:
IT equipment such as PCs, Media Centers and peripherals
TVs, Home Cinemas, Satellite and Digital Terrestrial Receivers and DVD recorders and players.
Modem and xDSL routers
Small household appliances
5 models in this range · quoted to order by an authorized Riello UPS reseller
Highlights
- Compact
- Silent operation
- Contemporary design
- Auto restart
- Low power consumption
Models & ordering
Riello model designations are the order codes. Each model is quoted to order; open a model for its full specification and to request pricing and lead time.
| Model | Rated power | Active power | Dimensions (h w d) | Weight | |
|---|---|---|---|---|---|
| IDG 400 | 400 VA | 240 W | 192x90x232 mm | 3.2 kg | Quote |
| IDG 600 | 600 VA | 360 W | 192x90x232 mm | 3.2 kg | Quote |
| IDG 800 | 800 VA | 480 W | 192x90x232 mm | 3.4 kg | Quote |
| IDG 1200 | 1200 VA | 720 W | 270x93x310 mm | 6.6 kg | Quote |
| IDG 1600 | 1600 VA | 960 W | 270x93x310 mm | 6.9 kg | Quote |
Ships from and sold by A5 IT.
| Input | |
| Rated power | 400 VA |
|---|---|
| Voltage | 220 / 230 / 240 V |
| Voltage tolerance | 230 V (+20/-25%) |
| Frequency | 50 / 60 Hz with automatic selection |
| OUTPUT and INVERTER OUTPUT | |
| Rated power | 400 VA |
| Active power | 240 W |
| Number phases | 1 |
| Wave form on battery | Pseudo Sinusoidal |
| Frequency on battery operation | 50 or 60 Hz (±1%) |
| Batteries | |
| Type | VRLA AGM maintenance-free lead based |
| Typical recharge time | 6-8 h |
| Environmental | |
| Communication | USB |
| Accessories provided | 2 output supply cables, user manual |
| Marks | CE |
| Operating temperature | 0 °C - +40 °C |
| Relative humidity | 5-95% non-condensing |
| Standards | European directives: L V 2014/35/EU low voltage; EMC 2014/30/EU electromagnetic compatibility -- Directive and Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; RoHS compliant |
| Data | |
| Weight | 3.2 kg |
| Dimensions (h w d) | 192x90x232 mm |
Characteristics
Maximum reliability in the protection of PCs thanks also to the monitoring and shutdown software PowerShield³, which you can download free of charge from our website by clicking here . Suitable for installation on PC’s with Windows operating systems 10, 8, 7, Hyper-V, 2019, 2016, 2012, and previous versions, Mac OS X, Linux. Low dimensions: with its compact shape, iDialog can be placed on any part of a desk or anywhere in the home. Noise-free running, iDialog is also suitable for protecting your non-professional, digital equipment items such as Home Cinema, CD Writers, DVD, Satellite and Digital Terrestrial receivers. 2-YEAR WARRANTY
